STRUX® Synthetic Macro-Fibers

High strength post-crack protection.

User Support Materials |

A replacement for welded wire mesh.

Welded wire mesh has long been used to reinforce slab-on-ground concrete, bridge decks and thin-walled precast applications for temperature and shrinkage crack control. Although mesh provides adequate performance, it adds many downsides. The mesh takes time to transport, install and correctly chair.

STRUX® products, such as STRUX® 90/40 synthetic macro-fibers, improves impact resistance, durability and long-term crack control properties of concrete by equally distributing structural fibers throughout the entire concrete matrix. There's no risk from corrosion, and none of the risk or job site obstruction inherent with the use of welded wire or mild steel reinforcement. STRUX® eliminates time and labor versus installing welded wire mesh (WWM). It eliminate the need to lift, carry, hoist, position, cut and tie awkward, heavy sheets or rolls of welded wire fabric (WWF) and thus helps to reduce construction time and labor cost for an estimated cost savings between 20-30%. Examples of applications where STRUX® can be used are slab on ground, precast element, elevated deck, tunnel liners  to replace non-structural steel.

Download our Strux Macrosynthetic Fiber Calculator



Documents

STRUX® Product Documents

Product Name Product Data Sheet SDS/MSDS
Precast Concrete Septic Tanks
Product Data Sheet
STRUX® 75/32 Synthetic Macro Fibers
Product Data Sheet
STRUX® 85/50 Synthetic Macro-Fiber
Product Data Sheet
SDS/MSDS
STRUX® 90/40 Synthetic Macro-fibers
Product Data Sheet
SDS/MSDS
STRUX® BT50 Synthetic Macro-Fiber
Product Data Sheet
SDS/MSDS
STRUX® M323 Synthetic Fiber Blend
Product Data Sheet
SDS/MSDS
STRUX® M324 Synthetic Fiber Blend
Product Data Sheet
SDS/MSDS

Lettres Techniques

Product Name PDF
Air-Detraining Agents
An Introduction to Self-Consolidating Concrete (SCC)
Chloride Ion Contribution of Admixtures to Concrete
Cold Weather Concrete
Definitions of Terms Relating to Self-Consolidating Concrete (SCC)
Factors Affecting Air Entrainment
Materials for Self-Consolidating Concrete (SCC)
Pervious Concrete — Placing, Consolidation and Curing
Self-Consolidating Concrete (SCC) Production Tips
STRUX® 90/40 Replaces WWF as Minimum Reinforcing for Composite Steel Floor Deck Construction
The Foam Index Test: A Rapid Indicator of Relative AEA Demand
Products & Accessories

Products

  • Product Name
  • Description
  • Key Benefits
  • Applications Type
STRUX® 75/32 Synthetic Macro Fibers
Description

STRUX® 75/32 fiber is a synthetic macro fiber complying with ASTM C1116/C1116M Type III, which can be used in ready-mixed concrete for different applications such slab-on-ground flooring, composite steel floor deck assemblies, topping slabs, thin-walled precast overlays and pavements.  Unlike traditional microfiber reinforcement, STRUX 75/32 macro fibers are specifically engineered to provide post-crack control performance.

Key Benefits
  • Can be used to completely or partially replace light rebar, welded wire reinforcement and steel fibers.
  • Easy to mix and fast to disperse.
  • Barely visible on the surface obtaining highly aesthetic concrete.
Application Type
STRUX® 85/50 Synthetic Macro-Fiber
Description

STRUX® 85/50 synthetic macro fibers are a unique form of high strength, high modulus synthetic macro reinforcement that is evenly distributed throughout the concrete matrix. It consists of synthetic macro fibers 50 mm (2 in.) in length with an aspect ratio of 85 that have specifically been designed to ensure ease of use and rapid dispersion in concrete. STRUX® 85/50 is used in concrete to improve the material properties including toughness (post crack energy absorption), impact and fatigue resistance, residual strength and durability.

Key Benefits
  • When added to shotcrete and concrete, the primary benefit of STRUX® 85/50 macro fiber is a significant improvement in flexural toughness.
Application Type
STRUX® 90/40 Synthetic Macro-fibers
Description

STRUX® 90/40 synthetic macro fibers are a unique form of high strength, high modulus synthetic reinforcement that is evenly distributed throughout the concrete matrix. The macro fibers add toughness, impact and fatigue resistance to concrete and improve residual strength and durability. Unlike traditional microfiber reinforcement, STRUX® 90/40 macro fibers are specifically engineered to provide post-crack control performance.

Key Benefits
  • Can be used to completely or partially replace light rebar, welded wire reinforcement and steel fibers.
  • Saves money through reduction or elimination of steel labor and material movement and storage costs, and fewer construction days.
  • Enhances jobsite safety by eliminating handling of steel fibers, welded wire reinforcement and rebar.
Application Type

STRUX® 90/40 macro fibers may be used in a variety of ready mix, precast and shotcrete applications including slab-on-ground flooring, overlays, pavements, bridge decks, composite steel floor deck assemblies, mass concrete, thin-walled precast elements (septic tanks, vaults, walls, etc.), tunnel linings, pool construction and slope stabilization.

STRUX® BT50 Synthetic Macro-Fiber
Description

STRUX® BT50 synthetic macro fiber reinforcement is a high strength, high modulus synthetic macro reinforcement that imparts toughness, impact and fatigue properties to concrete. STRUX® BT50 is a patented engineered design providing superior post-crack control performance with a broad range of applications.

Key Benefits
  • Unique packaging provides superior dispersion
  • Savings from reduced labor, material and storage costs and shorter construction time compared to secondary reinforcement
  • Enhances safety by eliminating handling of steel fibers, welded wire fabric or rebar
Application Type

STRUX® BT50 Synthetic Macro Fibers are engineered for ease of use, excellent dispersion and finishability in slab-on-ground flooring applications.

STRUX® M323 Synthetic Fiber Blend
Description

STRUX® M323 is a blended synthetic fiber complying with ASTM C1116/C1116M Type III, which can be used in ready-mixed concrete for different applications such slab-on-ground flooring, topping slabs and bridge decks.

Key Benefits
  • Can be used to completely or partially replace light rebar, welded wire reinforcement and steel fibers.
  • Easy to mix and fast to disperse.
  • Barely visible on the surface obtaining highly aesthetic concrete.
Application Type
STRUX® M324 Synthetic Fiber Blend
Description

STRUX® M324 is a blended synthetic fiber complying with ASTM C1116/C1116M Type III, which can be used in ready-mixed concrete for different applications such slab-on-ground flooring, topping slabs and bridge decks.

Key Benefits
  • Can be used to completely or partially replace light rebar, welded wire reinforcement and steel fibers.
  • Easy to mix and fast to disperse.
  • Barely visible on the surface obtaining highly aesthetic concrete.
Application Type
Overview

Shave off time from construction projects

In today's market, schedule is everything. Transporting, placing, and chairing welded wire mesh adds time to any project. STRUX® eliminates all that time—and its material characteristics make it as strong, if not stronger, than the alternative.

Add toughness to concrete with less material

STRUX® fibers add toughness, impact, and fatigue resistance to concrete. As opposed to microfiber reinforcement, STRUX® macro fibers add post-crack control performance. STRUX® allows users to save on material by decreasing thickness of slab on grade or overlays. For designers, this increases the range of possible forms. For contractors, this means less material overall may be needed. STRUX® reduces the time required for the critical path resulting in faster construction times and earlier delivery of the building for the contractor.

Get technical advice backed by experience

Our products don't exist in a vacuum. They're supported by our world-class technical experts, and STRUX® is no exception. Our experts will assist your organization in developing the perfect mix design to incorporate STRUX®. Our SDS Software can also calculate the necessary addition rate using the compressive strength of concrete, modulus of sub-grade reaction, thickness of concrete, and applied loads. For more information about STRUX® and how you can incorporate it into your product or design, contact GCP today.
